Alfagomma
T350LL & T350LH Series*
225 PSI Premium Paper Mill/Creamery Wash Down Hose – No Nozzle
GENERAL APPLICATIONS
- For general wash down service, using hot water or low pressure saturated steam in processing plants and facilities and in food and dairy plants
CONSTRUCTION
- Tube – White EPDM – Meets FDA and 3A (18-03) requirements
- Reinforcement – High tensile textile cords
- Cover – Red or white EPDM – heat, abrasion and ozone resistant
WORKING PRESSURE
Constant Pressure – 15 Bar (225 PSI)
STEAM PRESSURE
Constant Pressure – 6 Bar (90 PSI)
SERVICE TEMPERATURE RANGE
Water -40°F (-40°C) to +248°F (+120°C)
Steam +330°F to (+165°C)
BRANDING
ALFAGOMMA – ITALY – 350 6 BAR (90 PSI) STEAM 15 BAR (225 PSI) HOT WATER (embossed)
STANDARD LENGTH
200 feet – eliminates bulky hookups
| Series Number | ID | OD | Max. Working Pressure (psi) |
Standard Length (ft) |
Weight (lbs/ft) |
||
|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | ||||
| T350LL050 | 1/2 | 13 | 0.91 | 23 | 225 | 200 | 0.27 |
| T350LL062 | 5/8 | 16 | 1.02 | 26 | 225 | 200 | 0.31 |
| T350LL/LH075 | 3/4 | 19 | 1.22 | 31 | 225 | 200 | 0.44 |
| T350LL/LH100 | 1 | 25 | 1.46 | 37 | 225 | 200 | 0.54 |
| T350LL125 | 1 1/4 | 32 | 1.81 | 46 | 225 | 200 | 0.63 |
| T350LL150 | 1 1/2 | 38 | 2.05 | 52 | 225 | 200 | 0.74 |
| T350LL200 | 2 | 51 | 2.64 | 67 | 225 | 200 | 1.12 |
*T350 fully complies with the requirements listed in FDA CFR21.
COUPLING SUGGESTIONS: Short shank, long shank couplings (NPT, GHT), barbed inserts attached with bands.
