Alfagomma
T351LL & T351LG Series*
150 PSI EPDM Premium Paper Mill/Creamery Wash Down Hose with Tapered Nozzle
GENERAL APPLICATIONS
For general wash down service, using hot and cold water in paper mills and in food and dairy plants
CONSTRUCTION
- Tube – White EPDM. Meets FDA and 3A (18-03) requirements
- Reinforcement – Two ply, high tensile textile cords
- Cover – White or green EPDM – heat, abrasion and ozone resistant
WORKING PRESSURE
Constant Pressure – 10 Bar (150 PSI)
SERVICE TEMPERATURE RANGE
-40°F (-40°C) to +248°F (+120°C)
STANDARD LENGTH
50 feet including 6" long built-in tapered nozzle*
*Tapered Nozzle Hole Size
3/4" and 1" ID....3/8"
1 1/4" ID............1/2"
1 1/2" ID............5/8"
| Series Number | ID | OD | Max. Working Pressure (psi) |
Standard Length (ft) |
Weight (lbs/ft) |
||
|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | ||||
| T351LL/LG075 | 3/4 | 19 | 1.22 | 31 | 150 | 50 | 0.44 |
| T351LL/LG100 | 1 | 25 | 1.46 | 37 | 150 | 50 | 0.54 |
| T351LL/LG125 | 1 1/4 | 32 | 1.81 | 46 | 150 | 50 | 0.78 |
| T351LL/LG150 | 1 1/2 | 38 | 2.05 | 52 | 150 | 50 | 0.91 |
*T351 fully complies with the requirements listed in FDA CFR21.
COUPLING SUGGESTIONS: Short shank, long shank couplings (NPT, GHT), barbed inserts attached with bands.
