Alfagomma
T631AA Series
300 PSI Hot Tar & Asphalt Applicator Delivery Hose
GENERAL APPLICATIONS
- Hot tar and asphalt delivery service
CONSTRUCTION
- Tube – Black NBR – hot tar and asphalt resistant
- Reinforcement – High tensile steel wire braids
- Cover – Black CR – abrasion, ozone, hydrocarbon and fire resistant
WORKING PRESSURE
20 Bar (300 PSI)
SERVICE TEMPERATURE RANGE
-22°F (-30°C) to +356°F (+180°C)
BRANDING
ALFAGOMMA – ITALY T631 20 BAR (300 PSI) HOT TAR AND ASPHALT (embossed)
SAFETY FACTOR
10:1
| Part Number | ID | OD | Wall Thickness (mm) |
Max Rec. WP (psi) |
Vacuum Hg (in) |
Min. Bending Radius (in) |
Standard Length (ft) |
Weight (lbs/ft) |
||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | |||||||
| T631AA075 | 3/4 | 19 | 1.26 | 32 | 6 | 300 | 3 | 50/100 | 0.50 | |
| T631AA100 | 1 | 25 | 1.50 | 38 | 6 | 300 | 3 | 50/100 | 0.77 | |
COUPLING SUGGESTIONS:Permanently attached couplings are suggested for assemblies.
Kuriyama offers a full line of Quick-Acting couplings, pin lug shank couplings and combination nipples. Refer to current Kuriyama-Couplings™ and Accessories Catalog for type.
