Alfagomma
T253AA Series
150 PSI EPDM Layflat Water Discharge Hose
GENERAL APPLICATIONS
- High pressure, 150 PSI lay flat type hose for general industrial construction and irrigation
CONSTRUCTION
- Tube – Black EPDM
- Reinforcement – High tensile textile cords – 2 spirals up to 4", 4 spirals above 4"
- Cover – Black EPDM – abrasion and ozone-resistant
WORKING PRESSURE
Constant Pressure – 10 Bar (150 PSI)
SERVICE TEMPERATURE RANGE
-22°F (-30°C) to +176°F (+80°C)
BRANDING
ALFAGOMMA – ITALY – 253 10 Bar (150 PSI) EPDM WATER DISCHARGE (in green letters)
| Series Number | ID | OD | Max. Working Pressure (psi) |
Standard Length (ft) |
Weight (lbs/ft) |
||
|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | ||||
| T253AA150 | 1 1/2 | 38 | 1.81 | 46 | 150 | 100 | 0.37 |
| T253AA200 | 2 | 51 | 2.32 | 59 | 150 | 100 | 0.50 |
| T253AA250 | 2 1/2 | 63 | 2.80 | 71 | 150 | 100 | 0.60 |
| T253AA300 | 3 | 76 | 3.31 | 84 | 150 | 100 | 0.86 |
| T253AA400 | 4 | 102 | 4.33 | 110 | 150 | 100 | 1.19 |
| T253AA600 | 6 | 152 | 6.38 | 162 | 150 | 50/100 | 2.00 |
| T253AA662 | 6 5/8* | 168 | 7.01 | 178 | 150 | 50/100 | 2.17 |
| T253AA800 | 8 | 203 | 8.46 | 215 | 150 | 50/100 | 2.82 |
| T253AA1000 | 10 | 254 | 10.63 | 270 | 150 | 50/100 | 5.11 |
| T253AA1200 | 12 | 305 | 12.56 | 319 | 150 | 50 | 5.93 |
* 6 5/8" referred to as Elephant Trunk Hose – Ideal for “Irrigation Boots”
COUPLING SUGGESTIONS: Quick-Acting, pin lug, short shank couplings or combination nipples attached with single bolt, double bolt, wire or band type clamps.
Kuriyama offers a full line of Quick-Acting couplings, pin lug shank couplings and combination nipples. Refer to current Kuriyama-Couplings™ and Accessories Catalog for type.
