Products
CPCS Series (Galvanized Carbon Steel)
Center Punch Clamp
Features and Advantages
- Double wrapped for secure holding ability.
- A bolt free design provides for a professional low profile hose assembly.
- Compatible with most pneumatic or hand operated tools.
- Clamps are sold only by the box.
Material Specifications
- Galvanized carbon steel.
| Part Number | Clamp ID Size (in) |
Pieces Per Box |
Band Width (in) | Thickness Weight | Carton (lbs) |
Standard Carton |
|---|---|---|---|---|---|---|
| CPCS05 | 1 1/4 | 100 | 5/8 | 0.025 | 8.70 | 1 |
| CPCS06 | 1 1/2 | 100 | 5/8 | 0.025 | 9.70 | 1 |
| CPCS08 | 2 | 100 | 5/8 | 0.025 | 11.50 | 1 |
| CPCS10 | 2 1/2 | 50 | 5/8 | 0.025 | 6.80 | 1 |
| CPCS11 | 2 3/4 | 50 | 5/8 | 0.025 | 7.30 | 1 |
| CPCS12 | 3 | 50 | 5/8 | 0.025 | 7.70 | 1 |
| CPCS14 | 3 1/2 | 50 | 5/8 | 0.025 | 8.70 | 1 |
| CPCS16 | 4 | 25 | 5/8 | 0.025 | 4.90 | 1 |
| CPCS18 | 4 1/2 | 25 | 5/8 | 0.025 | 5.50 | 1 |
| CPCS20 | 5 | 25 | 5/8 | 0.025 | 5.90 | 1 |
| CPCS24 | 6 | 25 | 5/8 | 0.025 | 6.80 | 1 |
| CPCS28 | 7 | 25 | 5/8 | 0.025 | 7.40 | 1 |
| CPCS32 | 8 | 25 | 5/8 | 0.025 | 8.20 | 1 |
* Clamps only sold in box quantities
CPSS Series (201 Stainless Steel)
Center Punch Clamp
Features and Advantages
- Double wrapped for secure holding ability.
- A bolt free design provides for a professional low profile hose assembly.
- Compatible with most pneumatic or hand operated tools.
- Clamps are sold only by the box.
Material Specifications
- 201 stainless steel offers superior strength combined with good corrosion resistance to mild chemicals.
| Part Number | Clamp ID Size (in) |
Pieces Per Box |
Band Width (in) | Thickness Weight | Carton (lbs) |
Standard Carton |
|---|---|---|---|---|---|---|
| CPSS05 | 1 1/4 | 100 | 5/8 | 0.025 | 8.70 | 1 |
| CPSS06 | 1 1/2 | 100 | 5/8 | 0.025 | 9.70 | 1 |
| CPSS08 | 2 | 100 | 5/8 | 0.025 | 11.50 | 1 |
| CPSS10 | 2 1/2 | 50 | 5/8 | 0.025 | 6.80 | 1 |
| CPSS11 | 2 3/4 | 50 | 5/8 | 0.025 | 7.30 | 1 |
| CPSS12 | 3 | 50 | 5/8 | 0.025 | 7.70 | 1 |
| CPSS14 | 3 1/2 | 50 | 5/8 | 0.025 | 8.70 | 1 |
| CPSS16 | 4 | 25 | 5/8 | 0.025 | 4.90 | 1 |
| CPSS18 | 4 1/2 | 25 | 5/8 | 0.025 | 5.50 | 1 |
| CPSS20 | 5 | 25 | 5/8 | 0.025 | 5.90 | 1 |
| CPSS24 | 6 | 25 | 5/8 | 0.025 | 6.80 | 1 |
| CPSS28 | 7 | 25 | 5/8 | 0.025 | 7.40 | 1 |
| CPSS32 | 8 | 25 | 5/8 | 0.025 | 8.20 | 1 |
* Clamps only sold in box quantities
CPT Series
Center Punch Clamp Tool
Features and Advantages
- Designed to install and tighten center punch clamps around hoses.
- Racket action tensioning for ease of assembly.
- Durable heavy-duty carbon steel design.
- Portable for use in many different applications and locations.
Material Specifications
- Meets ASTM A366 for cold rolled carbon steel.
| Part Number | Weight Each (lbs) | Standard Carton |
|---|---|---|
| CPT300 | 3.00 | 1 |
