Products
KOA Couplings & Accessories
BUNA-40MPU Series
Sanitary Buna-N Tri-Clamp Gasket Black
BUNA-40MPUW Series
Sanitary Buna-N Tri-Clamp Gasket White
EPDM-40MPE Series
Sanitary EPDM Tri-Clamp Gasket Black
FKM-40MPSFY Series
Sanitary FKM Tri-Clamp Gasket Black
FKM-40MPSFYW Series
Sanitary FKM Tri-Clamp Gasket White
PTFE-40MPG Series
Sanitary PTFE Tri-Clamp Gasket White
SIL-40MPX Series
Sanitary FKM Tri-Clamp Gasket White
CERTIFICATION
- 3A 18-03 sanitary standard
SERVICE TEMPERATURE RANGE
- BUNA-40MPU & BUNA-40MPUW: -65°F (-54°C) to +210°F (+99°C)
- EPDM-40MPE: -60°F (-51°C) to +300°F (+149°C)
- FKM-40MPSFY & FKM-40MPSFYW: -20°F (-29°C) to +350°F (+177°C)
- PTFE-40MPG: -40°F (-40°C) to +450°F (+232°C)
- SIL-40MPX: -80°F (-62°C) to +450°F (+232°C)
| Part Number | Size (in) | Weight Each (lbs) | Standard Carton |
|---|---|---|---|
| BUNA-40MPU100 | 1 | 0.012 | 25 |
| BUNA-40MPU150 | 1 1/2 | 0.013 | 25 |
| BUNA-40MPU200 | 2 | 0.014 | 25 |
| BUNA-40MPU250 | 2 1/2 | 0.018 | 25 |
| BUNA-40MPU300 | 3 | 0.020 | 25 |
| BUNA-40MPU400 | 4 | 0.030 | 25 |
| BUNA-40MPU600 | 6 | 0.040 | 25 |
| BUNA-40MPUW100 | 1 | 0.012 | 25 |
| BUNA-40MPUW150 | 1 1/2 | 0.013 | 25 |
| BUNA-40MPUW200 | 2 | 0.014 | 25 |
| BUNA-40MPUW250 | 2 1/2 | 0.018 | 25 |
| BUNA-40MPUW300 | 3 | 0.022 | 25 |
| BUNA-40MPUW400 | 4 | 0.034 | 25 |
| Part Number | Size (in) | Weight Each (lbs) | Standard Carton |
|---|---|---|---|
| FKM-40MPSFY100 | 1 | 0.013 | 25 |
| FKM-40MPSFY150 | 1 1/2 | 0.014 | 25 |
| FKM-40MPSFY200 | 2 | 0.018 | 25 |
| FKM-40MPSFY300 | 3 | 0.030 | 25 |
| FKM-40MPSFY400 | 4 | 0.046 | 25 |
| FKM-40MPSFYW100 | 1 | 0.013 | 25 |
| FKM-40MPSFYW150 | 1 1/2 | 0.014 | 25 |
| FKM-40MPSFYW200 | 2 | 0.018 | 25 |
| FKM-40MPSFYW300 | 3 | 0.030 | 25 |
| FKM-40MPSFYW400 | 4 | 0.046 | 25 |
| Part Number | Size (in) | Weight Each (lbs) | Standard Carton |
|---|---|---|---|
| PTFE-40MPG100 | 1 | 0.013 | 25 |
| PTFE-40MPG150 | 1 1/2 | 0.014 | 25 |
| PTFE-40MPG200 | 2 | 0.018 | 25 |
| PTFE-40MPG300 | 3 | 0.028 | 25 |
| PTFE-40MPG400 | 4 | 0.040 | 25 |
| Part Number | Size (in) | Weight Each (lbs) | Standard Carton |
|---|---|---|---|
| SIL-40MPX100 | 1 | 0.012 | 25 |
| SIL-40MPX150 | 1 1/2 | 0.013 | 25 |
| SIL-40MPX200 | 2 | 0.014 | 25 |
| SIL-40MPX300 | 3 | 0.018 | 25 |
| SIL-40MPX400 | 4 | 0.030 | 25 |
