INCLUDED ACCESSORIES
Recessed Blade
Ventilation Port*
Pneumatic Foot Pedal
Diamond Blade
BLADE-DIA250
* Separate suction device required for fume extraction
OPTIONAL ACCESSORIES
Fume Extractor FUME-KCS4
Smooth Blade
BLADE-SMT250
Serrated Blade†
BLADE-SER250
† CAUTION: The included Serrated Blade is not recommended for use with hoses with a steel cover and/or containing steel helical reinforcement
KuriCrimp powered by o+p
KCS-TF5DI Series
DESCRIPTION
This stand alone unit is great for cutting a variety of either industrial or hydraulic hose. Ideal for cutting up to 3" six spiral hydraulic hose and up to 6" industrial hose. Suggested for use with KC4-V160 series crimpers.
| Hose Capacity (in) | Motor Strength (HP) | |
|---|---|---|
| 1 – 2 Wire | 3 | 10 |
| 4 SP / 6 SP | 3 | |
| Industrial | 6* | |
| Max opening (mm) | 195 | |
* Dependent on hose type
| Cutter Size | |
|---|---|
| L x W x H (in) | 44.9 x 46.1 x 40.2 |
| Weight (lbs) | 783 |
| Blade Diameter (mm) | 520 |
| Part Number | Motor Info |
|---|---|
| KCS-TF5DI-230/3 | 10 HP (230 V) 3 PH |
