Products
KuriCrimp powered by o+p
Replacement Blades
BLADE-SER Series
Serrated Replacement Blade
BLADE-SMT Series
Smooth Replacement Blade
BLADE-DIA Series
Diamond Replacement Blade
FEATURES AND ADVANTAGES
BLADE-SER
- Serrations help dissipate heat, extending blade life and reducing smoke generation.
- Acceptable for use with textile reinforced hoses.
- CAUTION: Serrated Blades are not recommended for use with hoses with a steel cover and/or containing steel helical reinforcement.
BLADE-SMT
- Smooth blades are suitable for use with hoses with a steel cover and/or steel helical reinforcement.
BLADE-DIA
- Durable diamond coating greatly extends blade life.
- Diamond blades are suitable for use with hoses with a steel cover and/or steel helical reinforcement.
| Part Number | Outside Diameter (mm) |
Inside Diameter (mm) |
Thickness (mm) |
|---|---|---|---|
| BLADE-SER250 | 250 | 40 | 3 |
| BLADE-SER350 | 350 | 50 | 3 |
| BLADE-SER400 | 400 | 50 | 4 |
| BLADE-SER520 | 520 | 50 | 4 |
| BLADE-SMT250 | 250 | 40 | 3 |
| BLADE-SMT350 | 350 | 50 | 3 |
| BLADE-SMT400 | 400 | 50 | 4 |
| BLADE-SMT520 | 520 | 50 | 4 |
| BLADE-DIA165 | 165 | 20 | 1.4 |
| BLADE-DIA250 | 250 | 40 | 3 |
| BLADE-DIA350 | 350 | 50 | 3 |
| BLADE-DIA400 | 400 | 50 | 4 |
| BLADE-DIA520 | 520 | 50 | 4 |
CAUTIONARY STATEMENTS:
Blade sharpening should only be performed by the blade manufacturer. (Contact Kuriyama Customer Service for sharpening service details.)
Ensure direction of blade rotation is correct as indicated by the arrow printed on the blade. When using a new blade or newly sharpened blade, make initial hose cuts at a low speed. A newly sharpened blade will cut very quickly, which at a high speed could lead to overheating, potentially damaging the blade.
- Do not operate at excessive speeds that could potentially overwork the motor.
- Do not move or rotate the hose during cutting.
- Do not apply any solvents or lubricants to the blade.
When replacing the blade inspect for signs of wear, that the shaft rotates without vibrations and that the blade is perfectly perpendicular to the cutting surface. Before starting, actuate the hose pressing lever to ensure no interferences.
