Tigerflex
Tiger™ Blue TBLU™ Series
EPDM Suction Hose
GENERAL APPLICATIONS
- Agriculture liquid fertilizers
- Irrigation lines
- Liquid manure handling
- Marine bilge discharge
- Pumps, rental and construction dewatering
- Pumps, trash
- Septic and wastewater handling
- Used frack solution removal
- Water suction – standard duty
CONSTRUCTION
EPDM tube with polyethylene helix
SERVICE TEMPERATURE RANGE
-40°F (-40°C) to +160°F (+71°C)*
*Actual service temperature range is application dependent.
FEATURES AND ADVANTAGES
- Superior Rubber Compounds – Tigerflex™ uses only the best available EPDM compounds, which provide the ideal combination of light-weight, flexibility, durability and chemical resistance.
- Superior Flexibility – Our tests show up to 22% more flexible than the competition, especially in sub-zero weather! Tiger™ Blue Hose is more flexible coming off the truck and easier to handle than other similar hoses.
- Easy Slide Helix – Rigid helix design protects hose tube from cover wear, and allows hose to slide easily over rough surfaces and around corners. Easy-to-handle.
- Convoluted Cover Design – Provides increased hose flexibility.
- “Cold-Flex” Materials – Hose remains flexible in sub-zero temperatures.
| Part Number | ID | OD | Working Pressure
(psi) |
Vacuum Rating Hg (in) |
Min. Bending Radius at 68°F (in) |
Standard Length (ft) |
Weight (lbs/ft) |
||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | at 68°F | at 104°F | at 68°F | at 104°F | ||||
| TBLU200 | 2 | 50.8 | 2.51 | 63.8 | 50 | 35 | FULL | 28 | 5 | 100 | 0.67 |
| TBLU300 | 3 | 76.2 | 3.60 | 91.5 | 45 | 30 | FULL | 26 | 7 | 100 | 1.14 |
| TBLU400 | 4 | 101.6 | 4.70 | 119.5 | 40 | 25 | FULL | 26 | 11 1/2 | 100 | 1.84 |
NOTES:
• Service life may vary depending on operating conditions and type of material being conveyed.
• Other colors available upon request. Minimum order quantity may apply. contact Kuriyama customer service for details.
• Contact your nearest KOA warehouse for availability of 50 ft. lengths.
COMPLIANCES (click here for details)
RoHS (11)
