AutolockAutolock

AL Series

Braided Push-On Hose

GENERAL APPLICATIONS

  • Air tools
  • Pneumatic and low-pressure hydraulic systems
  • Lubricating oils, diesel fuel and antifreeze solutions
  • Water lines for molding and blow-forming machines
  • Robotic welders
  • Chemical and paper industries
  • Automation and machine tools

CONSTRUCTION

  • Tube – Oil-resistant synthetic rubber NBR (ARPM Class A)
  • Reinforcement – High-strength textile braid for secure fitting retention
  • Cover – Abrasion, ozone, and flame resistant NBR cover (MSHA-approved)

SERVICE TEMPERATURE RANGE

-40°F (-40°C) to +212°F (+100°C)*
-40°F (-40°C) to +160°F (+70°C) for air transfer*
*Actual service temperature range is application dependent.

SAFETY FACTOR

4:1

BRANDING

ALFAGOMMA – AUTOLOCK EVOLUTION – NON CONDUCTIVE ___ [ID Size] WP ___ PSI FLAME RESISTANT MSHA IC-152/21 – [Date Code]

PACKAGING

  • Reels of various lengths (see chart)
  • Max two or three** pieces per reel (Min piece length 50')
    **Max three pieces for 1/4" through 1/2" ID, max two pieces for 5/8" through 1"

FEATURES AND ADVANTAGES

  • Push-On Assembly: Easy to connect, no clamps or tools required.
  • Flame Resistance: MSHA-approved cover for safety in hazardous environments (No. IC-152/21).
  • Durable Construction: Long-lasting, resistant to wear, ozone, and hydrocarbons.
  • Oil Resistant Tube: Meets APRM Class A (High Oil Resistance) Rating, for use with gasoline, diesel, bio-diesel and kerosene.
  • Non-conductive Tube and Cover^: Helps protect user from shock when used near high-voltage sources.
    ^ Meets a minimum of 1,000,000 ohms per inch resistance when tested with a 1,000-volt D.C. megger.
  • Mandrel-Built Braided Construction Quality:
    • Stable under pressure with minimal expansion and twisting
    • Better kink resistance and dimensional consistency
    • Superior pressure tolerance compared to competitors
    • Highly flexible design, works well in tight spaces
Series Number Color ID OD Working Pressure
(psi) 		Approximate
Reel Length (ft) 		Packaging†
(per reel)		 Weight
lbs/ft
(in) (mm) (in) (mm)
AL-04BK Black 1/4 6 0.51 13 400 600 Max 3 pieces of
various lengths 		0.09
AL-05BK Black 5/16 8 0.55 14 400 600 0.1
AL-06BK Black 3/8 10 0.63 16 400 600 0.12
AL-08BK Black 1/2 13 0.75 19 400 550 0.15
AL-10BK Black 5/8 16 0.91 23 350 350 Max 2 pieces of
various lengths 		0.21
AL-12BK Black 3/4 19 1.06 27 300 350 0.25
AL-16BK Black 1 25 1.34 34 250 200 0.35
AL-04BU Blue 1/4 6 0.51 13 400 600 Max 3 pieces of
various lengths 		0.09
AL-06BU Blue 3/8 10 0.63 16 400 600 0.12
AL-08BU Blue 1/2 13 0.75 19 400 550 0.15
AL-10BU Blue 5/8 16 0.91 23 350 350 Max 2 pieces of
various lengths 		0.21
AL-12BU Blue 3/4 19 1.06 27 300 350 0.25
AL-16BU Blue 1 25 1.34 34 250 200 0.35
AL-04GR Green 1/4 6 0.51 13 400 600 Max 3 pieces of
various lengths 		0.09
AL-06GR Green 3/8 10 0.63 16 400 600 0.12
AL-08GR Green 1/2 13 0.75 19 400 550 0.15
AL-10GR Green 5/8 16 0.91 23 350 350 Max 2 pieces of
various lengths		 0.21
AL-12GR Green 3/4 19 1.06 27 300 350 0.25
AL-04GY Gray 1/4 6 0.51 13 400 600 Max 3 pieces of
various lengths		 0.09
AL-06GY Gray 3/8 10 0.63 16 400 600 0.12
AL-08GY Gray 1/2 13 0.75 19 400 550 0.15
AL-10GY Gray 5/8 16 0.91 23 350 350 Max 2 pieces of
various lengths		 0.21
AL-12GY Gray 3/4 19 1.06 27 300 350 0.25
AL-04RD Red 1/4 6 0.51 13 400 600 Max 3 pieces of
various lengths 		0.09
AL-06RD Red 3/8 10 0.63 16 400 600 0.12
AL-08RD Red 1/2 13 0.75 19 400 550 0.15
AL-10RD Red 5/8 16 0.91 23 350 350 Max 2 pieces of
various lengths 		0.21
AL-12RD Red 3/4 19 1.06 27 300 350 0.25
AL-16RD Red 1 25 1.34 34 250 200 0.35
AL-04YL Yellow 1/4 6 0.51 13 400 600 Max 3 pieces of
various lengths 		0.09
AL-06YL Yellow 3/8 10 0.63 16 400 600 0.12
AL-08YL Yellow 1/2 13 0.75 19 400 550 0.15
AL-10YL Yellow 5/8 16 0.91 23 350 350 Max 2 pieces of
various lengths 		0.21
AL-12YL Yellow 3/4 19 1.06 27 300 350 0.25

† Min length 50 ft
Hose is priced per foot

Because we continually examine ways to improve our products, we reserve the right to alter specifications or discontinue products without prior notice.
